Machine Moving Skate Set CORMAK WL6+WF6 12t

Professional machine moving skate set WL6 + WF6 is a reliable tool for relocating heavy machinery, industrial equipment and structural components. Thanks to its robust construction, high load capacity and polyurethane treads, this set ensures safe and efficient transport in industrial plants, workshops and warehouses. A key advantage of this solution is the ability to manoeuvre even in narrow spaces without the risk of damaging floor surfaces or the load itself.

Main advantages of the WL6 + WF6 skate set

• High static and dynamic load capacity – up to 6,000 kg static and 3,600 kg dynamic per unit, allowing safe transport of very heavy objects.
• Polyurethane treads – effective protection of floor surfaces and transported loads against damage.
• Low loading height (110 mm) – makes it easy to position the skates under equipment without lifting it to a significant height.
• Compact design and steering angle of ±90° – ensures full control and easy manoeuvring even in confined spaces.
• Stability and precise positioning – achieved through proper bogie spacing and support points (1 for WL6, 2 for WF6).

Design and technology – construction optimised for industrial loads

The components of the set have been designed with maximum durability and operational safety in mind. WL6 and WF6 machine skates are made from materials resistant to abrasion and deformation, ensuring long service life even under intensive industrial conditions.

Main components of the set:

• 80x80 mm rollers – made of polyurethane, ensuring quiet and smooth operation even on uneven surfaces.
• Solid load beds – load-bearing surface Ø155 mm (WL6) and 200x180 mm (WF6), contributing to even load distribution and transport stability.
• Connecting bar with a length of 1300 mm – allows flexible adjustment of bogie spacing in the range of 450 – 1,700 mm.
• Steering handle with a length of 1080 mm – with a turning angle of ±90°, increasing control during manoeuvring.

Precision and operational efficiency – safety and time savings

The well-designed WL6 + WF6 set minimises the risk of load shifting or tipping during transport. Thanks to the use of high-quality polyurethane tread rollers, rolling resistance is reduced, which translates into less force required to move heavy equipment. The operator gains full control over the transport process, while relocation time is significantly reduced.

Applications – versatile support for multiple industries

The WL6 + WF6 machine moving skate set is used across many sectors, including:

• machinery industry – transport of machine tools and production lines,
• logistics and warehousing – relocation of racking systems and steel structures,
• construction industry – movement of prefabricated elements,
• technical service and installation – transport of generators, tanks and control cabinets.

Thanks to its compact design and high load capacity, the set can be used both for installing new production lines and during servicing or modernisation works.

Standard equipment

• 1 × WL6 machine moving skate
• 1 × WF6 load skate
• 1300 mm connecting bar
• Steering handle with ±90° turning range

Technical data of the WL6 + WF6 set

Choose safety and efficiency – select the WL6 + WF6 skate set

If you are looking for a reliable solution for the safe relocation of heavy machinery and equipment, the WL6 + WF6 machine moving skate set is an investment that will significantly improve your operations. High build quality, refined design and excellent manoeuvrability make it an essential piece of equipment for any industrial facility.
