Conventional Universal Lathe Set CORMAK 500x1000/65 with Turning Tools and Live Centre

Professional universal lathe for precise metal machining – CORMAK 500x1000/65

The CORMAK 500x1000/65 universal lathe is a high-class conventional lathe designed for demanding machining tasks in production plants, toolrooms and locksmith workshops. The machine enables precision metal machining across a wide range of operations – from rough turning to threading and drilling. The set includes a complete set of 25x25mm turning tools and a live centre MK5, providing a ready-to-use, fully equipped solution.

Main advantages of the machine

• Solid cast iron bed 325mm wide – excellent vibration damping and turning stability.
• Large spindle bore 65mm allows machining of long parts with larger diameters.
• High-quality spindle bearing system ensures smooth and quiet operation.
• Hardened and ground gears – durability of the drive mechanism even under heavy use.
• 3-axis digital readout (X, Y, Z) – improved precision and process control.
• Rapid longitudinal feed reduces machining time and increases productivity.
• Threading versatility: metric, inch, module and D.P. – without the need to change gears.
• Removable bed bridge – allows machining of components up to 630mm in diameter.

Design and technology

The lathe structure is based on a monolithic cast iron body, providing excellent rigidity even under heavy load. The spindle, featuring a CAMLOCK D1-6 mount and MK7 taper, is driven by a 5.5kW main motor, offering smooth speed regulation from 18 to 1600rpm across 15 gears. The toolpost accommodates 25x25mm cutting tools, ensuring compatibility with a wide range of tooling systems.

Precision and performance

With its digital position readout, precisely ground guideways and automatic feeds, the CORMAK 500x1000/65 metal lathe guarantees dimensional repeatability and a high-quality surface finish. The integrated thread dial indicator and the ability to cut both right- and left-hand threads make it a versatile and professional machine. The ergonomic control panel allows quick adjustment of working parameters for optimal performance.

Applications

This model is suitable for:

• single and small-batch production,
• shaft and machine component repair,
• maintenance and service workshops,
• toolmaking and locksmith industries.

Standard equipment

• Set of 25x25mm turning tools – 7 pcs (with carbide inserts)
• Live centre MK5
• 3-axis digital readout
• 3-jaw chuck 250mm
• Faceplate 435mm
• Fixed and travelling steadies
• Cooling system with pump
• LED work light
• Set of service tools and wrenches
• User manual, CE Declaration of Conformity

Optional equipment

• Grinding attachment PS125
• Cutting fluid ES-12
• Taper turning attachment

Technical parameters

The CORMAK 500x1000/65 universal lathe is a reliable tool for professionals who demand precision, durability and high efficiency. Order now and enhance your production capabilities.
