Conventional Universal Lathe CORMAK 560x1500

Conventional Universal Lathe CORMAK 560x1500 – Precision Machine for Advanced Metalworking

CORMAK 560x1500 is a robust and precise universal lathe designed for a wide range of machining applications in industrial environments, locksmith workshops and toolrooms. Built for intensive use, it offers a large 105mm spindle bore, rigid cast-iron bed and capability to machine parts up to 785mm in diameter with the gap bridge removed. The model stands out with its high stiffness, accuracy and operator ergonomics, ensuring efficiency and reliability in daily operation.

Main advantages

• Wide machining capability – cylindrical and conical turning, polishing, drilling, broaching, metric, inch, module and DP threading.
• Cast-iron, hardened and ground bed construction – reduces vibration and increases precision.
• Central feed control system – enables quick parameter adjustment.
• 3-axis digital readout (longitudinal, cross, top slide) – ensures dimensional accuracy and control.
• Reinforced spindle bearings – stable operation under high load conditions.
• Powerful 7.5/9kW motor and 315mm chuck – suitable for large and heavy workpieces.
• Rapid feed system – shortens tool travel times and increases machining efficiency.
• Precision gearbox with hardened gears – ensures durability and reliability of the drive system.
• Comprehensive threading range without gear changes – up to 196 combinations.
• Thread dial indicator – improves repeatability and reduces setup time.
• Removable gap bridge – allows turning of workpieces up to 785mm in diameter.

Construction and technology

The machine is built on a rigid 350mm-wide bed ensuring stability during operation. The ergonomic control panel allows smooth spindle speed adjustment within the 25–1600rpm range. A built-in cooling system, LED lighting and steady rests for long shafts enhance safety and operator comfort. High-quality mechanical components and precisely ground guideways guarantee accuracy in both single-part and series production.

Applications

The CORMAK 560x1500 conventional lathe is ideal for the machine-building industry, maintenance services, technical schools and production departments. It allows efficient machining of shafts, sleeves, flanges, discs and other steel, cast-iron and non-ferrous components.

Technical data

Standard equipment

• 3-axis digital readout (optical scale)
• 3-jaw chuck 315mm
• 4-jaw independent chuck 400mm
• Faceplate 450mm
• Fixed and travelling steadies
• Dead centre MK5
• Cooling system
• Work light
• Chuck and toolpost wrench
• Service tools set
• Operating manual
• CE declaration of conformity

Optional equipment

• Set of 25x25mm turning tools (9 pcs)
• Precision live centre MK5
• Grinding attachment PS125
• Cutting fluid ES-12

Choose proven quality and precision. Select the CORMAK 560x1500 metal lathe – reliability for professionals.
