Belt Grinder for Metal CORMAK BS75-200 with Extraction – Powerful, Clean and Precise Grinding

The CORMAK BS75-200 belt grinder is an industrial-grade machine designed for intensive use in production facilities, metal workshops and toolrooms. This belt grinder for metal combines high grinding efficiency with an effective dust extraction system, ensuring safety, cleanliness and comfort in daily operation. The robust steel construction and large worktable provide stability and precision, even when processing large workpieces.

Main Advantages of the Machine

• Two belt speeds (15 / 30 m/s) – adjust the speed to the material type and operation (rough or finishing grinding).
• Integrated dust extraction system – ensures a clean and safe working environment without the need for external extraction units.
• Stable steel construction – effectively reduces vibration, improving repeatability and surface quality.
• Large worktable (480 × 75 mm) – enables convenient operation with larger workpieces.
• Stepless grinding angle adjustment – allows precise belt positioning for different shapes and angles.
• Quick belt change system – minimises downtime and increases working efficiency.

Design and Technology

The stationary CORMAK BS75-200 grinder is based on a welded steel frame providing rigidity and resistance to dynamic loads. The built-in extraction system with a 0.37 kW motor and two Ø100 mm outlets ensures high dust and swarf removal efficiency. The main motor with 3.3 kW power delivers sufficient performance for demanding metal grinding applications.

Precision and Efficiency

With a belt width of 75 mm and length of 2000 mm, the machine offers a large contact surface that shortens processing time and enhances productivity. Two belt speeds allow quick switching from heavy stock removal to precision finishing. The ergonomic design and spring-loaded belt tensioning system maintain optimal tension throughout the operation.

Applications

The CORMAK BS75-200 metal belt grinder is used in:

• Production facilities working with steel, stainless steel and aluminium,
• Welding and locksmith workshops,
• Surface preparation and finishing areas,
• Grinding of edges, welds and flat surfaces.

Standard Equipment

• Stable steel base with adjustable tilt
• Abrasive belt 2000 × 75 mm
• Built-in extraction system with bag and Ø100 mm connectors
• Anti-spark and anti-dust guard
• Tilting protective cover
