Dual-Column Semi-Automatic Metal Bandsaw CORMAK BS600H

Dual-Column Bandsaw CORMAK BS600H – precision and reliability in industrial cutting

The Dual-Column Bandsaw CORMAK BS600H is a high-performance machine designed for cutting solid bars, pipes, and profiles made of steel and non-ferrous metals in a semi-automatic cycle. Its rigid construction, use of high-quality components, and automated cutting process make it an excellent tool for demanding industrial production environments.

Main advantages of the machine

• Stable dual-column construction ensures precision and rigidity during cutting.
• Automatic work cycle: hydraulic vice, cutting blade, and arm lifting functions.
• Cast-iron arm – durability and resistance to torsion.
• Guides with bearings and carbide inserts for cutting accuracy.
• Automatic machine stop in case of blade breakage.
• ABB motor guaranteeing long-term reliability.

Design and technology

The machine operates in a fully semi-automatic cycle. Once started, the operator only feeds the material to the stop, while all other functions – clamping the workpiece, starting the blade, lowering and raising the arm, and releasing the vice – are performed automatically. The CORMAK BS600H metal bandsaw ensures stable operation even when cutting large cross-sections, thanks to a wide blade and powerful drive system.

Precision and performance

The CORMAK BS600H metal bandsaw is equipped with a 6300 × 41 × 1.3 mm blade and a four-speed system allowing operation at 28, 52, 74, and 85 m/min. This enables optimal adjustment of cutting speed to the material type and hardness. The powered cleaning brush and coolant system significantly improve working conditions and extend the blade’s lifespan.

Applications

This machine is ideal for cutting large-section components, including pipes, angles, closed profiles, and solid bars. It is a versatile bandsaw for pipes and profiles designed for construction, production, and metalworking facilities.

Standard equipment

• Control panel with a clear interface
• Powered blade cleaning brush
• Cooling system with a closed circuit
• Bimetallic cutting blade included
• CE Declaration of Conformity
• User manual

Technical data
