Reference:
HR350SA
Automatic Bandsaw CORMAK HR350SA is an advanced technological solution for professional industrial plants requiring high efficiency, repeatability, and precision. With modern components and a double-column structure, this metal bandsaw ensures reliable operation even under intensive production conditions. The saw supports both manual and fully automatic modes, allowing the operator to adapt the operation to individual needs and the type of material being cut.
Polish manufacturer
Top Quality
Warranty service
and post-warranty service
CE certificates
We comply with EU standards
12 / 24-month warranty
Secure purchase
Automatic Bandsaw CORMAK HR350SA – precise metal cutting in automatic mode
Automatic Bandsaw CORMAK HR350SA is an advanced technological solution for professional industrial plants requiring high efficiency, repeatability, and precision. With modern components and a double-column design, this metal bandsaw provides reliable performance even in demanding production environments. The saw operates in both manual and fully automated modes, enabling the operator to adjust the working method according to specific requirements and material type.
Main advantages of the machine
- Automatic cutting cycle – full automation of clamping, feeding, cutting, and arm lifting processes.
- Double-column design – ensures exceptional rigidity and precise blade guidance.
- Top vise clamping – allows safe and efficient cutting of tube and profile bundles.
- Hydraulic feeding system – precise positioning of the workpiece with ±0.2 mm accuracy.
- Intuitive control – LCD touchscreen panel for quick setting of cutting parameters.
Construction and technology
The saw frame is made of cast iron, ensuring excellent vibration damping and stability during operation. The supporting frame is inclined at 3° to the table, improving efficiency when cutting rectangular-section components. The blade guiding system is based on precision bearings and carbide inserts, reducing blade wear and enhancing cutting quality. Hydraulic blade tensioning and a three-speed motor with an inverter guarantee perfect adaptation of parameters to the material type.
Precision and work efficiency
The throttling valve enables smooth regulation of the arm lowering speed, allowing controlled cutting without the risk of damaging the workpiece. The rapid feed system shortens the cutting cycle, while the cleaning brush and coolant system increase saw lifespan. This is a reliable solution for demanding customers expecting efficiency and repeatability.
Application
The HR350SA model is the ideal bandsaw for cutting tubes and profiles, structural and stainless steels, and other metals. It is designed for use in locksmith workshops, manufacturing companies, and machining centres where high quality, automation, and safety are essential.
Standard equipment
- Automatic and manual operating modes
- Control panel with LCD touchscreen
- Hydraulic vice with top pressure
- Powered blade cleaning brush
- Hydraulic blade tensioning
- Coolant system
- Bimetal bandsaw blade
- CE certification
Optional equipment
- Roller feed table extensions
Technical data:
| Cutting range | Ø350 mm / 350 x 350 mm |
| Blade | 4515 x 34 x 1.1 mm |
| Cutting speeds | 27 / 45 / 69 m/min |
| Total power | 4.8 kW |
| Hydraulic unit | 0.75 kW |
| Coolant pump | 0.04 kW |
| Blade tensioning | hydraulic |
| Feeder stroke | 500 mm |
| Load capacity | 1,500 kg |
| Table height | 700 mm |
| Dimensions (L x W x H) | 2800 x 2200 x 1700 mm |
| Weight | 1,500 kg |
Choose the Automatic Bandsaw CORMAK HR350SA if you are looking for durability, precision, and efficiency in one. Contact our advisor to receive an offer tailored to your production needs.
