Construction

• Rigid welded steel frame ensuring durability and stability,
• Gantry arms made of thick, hardened, powder-coated steel for improved stiffness and precision,
• Hybrid worktable design,
• Equipped with T-slots for manual material clamping — working area 2100 x 4000 mm.

Drive System

• Servo motors provide dynamic motion and fast acceleration, ensuring accuracy across all axes,
• X and Y axes feature high-quality rack-and-pinion drives for precise motion,
• Z axis driven by a precision ball screw,
• All axes move on linear guideways,
• Equipped with a tool height sensor,
• Linear bearings: trapezoidal rails with Hiwin carriages.

Spindle

• High-quality brushless spindle designed for long service life,
• Equipped with an innovative air-cooling system — no liquid cooling required,
• Utilises precision machine bearings for quiet and reliable operation,
• Tool height measurement sensor included,
• Spindle speed range: 4,500–18,000 rpm,
• Tool clamping via ER32 collets.

Software

• OPTIONALLY latest software UCanCAM V13 (supports import/export from Corel, AutoCAD, etc.; includes text editor and other advanced features),
• Enables quick and intuitive element design and automatic G-code conversion,
• Includes G-code memory — resumes operation after power failure from the last cutting point.

DSP Control

• Digital Signal Processing – digital control for smooth and accurate operation,
• DSP controller has its own processor and memory ensuring stable, independent operation,
• Guarantees precise machining and reliability,
• No need to reload programs after power interruption,
• Internal memory allows operation without re-uploading programs.

We provide genuine CE-certified machines — approved by leading EU institutions.

By choosing CORMAK, you ensure precision, durability, and operator safety.

We offer warranty and post-warranty service. Machine training and/or commissioning available upon request — please contact our consultant.

The price quoted refers to the machine only and excludes additional equipment, installation, transport, and training.

Technical Parameters

Equipment

• Air-cooled spindle, premium version
• Hybrid servo drives
• Vacuum table – 4 independent zones + T-slot table for manual material clamping (clamps included)
• Tool height sensor included
• Tool set, collets, levelling feet, and other accessories
• DSP control system – digital signal processing
• Starter tool kit

Unloading and machine placement are the customer’s responsibility.

Power plug supplied by the customer due to different 16A / 32A socket standards.

On-site commissioning of CNC routers available upon request, with individual pricing.

CNC Milling Router Commissioning
