Vertical Bandsaw CORMAK HBS450N with Laser Indicator

CORMAK HBS450N Bandsaw with Laser Indicator – Precision Cutting of Metal and Wood for Professional Applications

Key Machine Advantages

• Laser indicator – facilitates straight-line cutting guidance and increases operating precision.
• Quick blade tensioning lever – enables rapid blade replacement without the need to readjust the tension.
• Precision cast iron worktable – provides stability and allows angle adjustment from -10° to +45°.
• Blade tension indicator – the integrated viewing window gives the operator full control over blade tension and cutting parameters.
• Two blade speeds – allows selection of the optimum speed (7 or 14m/s) according to the material being cut.
• Large cutting capacity – a cutting height of up to 280mm and width of up to 465mm enable the processing of large and thick workpieces.

Construction and Technology

The HBS450N model is built around a stable steel frame and a heavy, vibration-damping cast iron table that effectively absorbs vibrations. The bandsaw is equipped with 480mm diameter drive wheels, ensuring smooth blade guidance and a long service life for its components. In addition, the dust extraction system with a 2×100mm extraction port helps maintain a clean working environment, which is important when cutting wood or plastics.

The machine is driven by a three-phase motor rated at 2.2kW (S1), with the capability of temporarily increasing power to 3.1kW (S6). The pulley system enables smooth switching between speeds according to the material type and operating requirements.

Cutting Precision and Productivity

The CORMAK HBS450N bandsaw delivers high cut edge quality even when processing demanding materials, thanks to correct blade tension, stable construction and precise table angle adjustment. The laser indicator minimises the risk of errors, significantly reducing the time required for material preparation and cutting guide setup.

Applications

The machine is designed for professional applications:

• cutting non-ferrous metals, structural steel and stainless steel,
• cutting plastics and hard composite materials,
• production of tooling components and prototypes,
• metalworking shops, mechanical workshops, technical schools and laboratories.

Standard Equipment

• On/off switch with overvoltage release
• 2×100mm dust extraction port
• Precision fence
• 3,605×20mm bandsaw blade, 8 TPI

Optional equipment*

• 100mm dust extraction hose
• Galvanised hose clamp
• Mobile base with a capacity of up to 260kg

Technical Specifications

Looking for a reliable bandsaw for precision cutting tasks? CORMAK HBS450N is a proven tool for professionals. Contact us to learn more about the offer and model availability.

*The indicated price refers exclusively to the machine and does not include optional/additional equipment, installation, transport, or training; please contact our advisor for more information.
