Welding Cobot CORMAK R950 6-Axis Cobot for Automation 5kg 922mm
The CORMAK R950 ROBOT is a compact 6-axis cobot designed for production automation, assembly, packaging, CNC machine tending and pick & place tasks. With a 5kg payload, 922mm reach and ±0.02mm repeatability, it provides high precision, flexible operation and easy integration with existing production workstations.
CORMAK R950 ROBOT – a 6-axis collaborative robot for production automation
The CORMAK R950 is a state-of-the-art 6-axis collaborative robot designed for the automation of processes in production, assembly, packaging, machine tending and pick-and-place applications. Its compact design, high repeatability and ease of integration make it well-suited for both new workstations and the modernisation of existing production lines. The robot offers a payload of 5 kg, a working reach of 922 mm and repeatability of ±0.02 mm.
Key advantages of the robot
- Six axes of motion enable flexible operation across a wide range of industrial applications.
- A payload of 5 kg allows for the handling of workpieces, tools and lightweight production components.
- The 922 mm working reach provides a wide working area whilst maintaining compact dimensions.
- A repeatability of ±0.02 mm guarantees high precision in the operations performed.
- A typical TCP speed of 1 m/s enables efficient execution of repetitive tasks.
- Installation in any position facilitates the robot’s integration into existing workstations.
- Extensive communication options: Modbus, Profinet, Ethernet and IO allow for easy connection to automation systems.
- Programming in C#, C++, Python, Java and ROS enhances implementation and integration capabilities.
- Its compact design and weight of 22 kg make installation easy, even in confined spaces.
- IP54 protection rating ensures resistance to conditions typical of an industrial environment.
Design and technology
The ROBOT R950 has been designed for use in modern production facilities where repeatability, safety, space-saving and the ability to commission quickly are key. The aluminium and steel construction ensures adequate rigidity, durability and stability during repetitive movements.
The robot can be used as a stand-alone workstation or as part of a larger automation system. Thanks to its 6-axis design, it is suitable for both simple handling tasks and more demanding technological processes requiring high motion accuracy.
Precision and operational efficiency
High repeatability of ±0.02 mm ensures consistent process quality, regardless of the number of cycles performed. The robot is well-suited to tasks requiring precise positioning, such as part handling, sorting, packaging, adhesive application, assembly, screwdriving or operating CNC machines.
Thanks to its compact design and the ability to be mounted in any position, the CORMAK R950 ROBOT can be easily adapted to various workstations, both new and existing. This solution helps to reduce the amount of manual labour, increase process repeatability and improve production organisation.
Applications
The CORMAK R950 ROBOT is designed for the automation of warehousing, industrial and manufacturing processes. It is ideal for tasks requiring repetitive movements, precise manipulation and stable operation over long periods.
- Pick and place
- Loading and unloading of workpieces
- CNC machine operation
- Packaging and sorting
- Adhesive application
- Assembly and screwing
- Light manufacturing and laboratory processes
- Handling of components
- Operating production workstations
Standard equipment
- Robot arm
- Control station
- Cabling kit
- Safety button
Ready-to-use kit
The kit contains all the essential components needed to get started. This means the robot is ready for commissioning and programming straight out of the box. This solution allows you to quickly put the robot into operation and minimise the time needed to set up the workstation.
Technical specifications
| Type | collaborative robot, 6-axis |
| Payload | 5 kg |
| Maximum payload | 7 kg |
| Working reach | 922 mm |
| Repeatability | ±0.02 mm |
| Typical TCP speed | 1 m/s |
| Mass | 22 kg |
| Protection class | IP54 |
| I/O | DI x16, DO x16, AI x2, AO x2 |
| Communication | Modbus, Profinet, Ethernet, IO |
| Development environment | C#, C++, Python, Java, ROS |
| Permissible operating temperature | 0–45°C |
| Permissible relative humidity | 90% RH |
| Installation | any position |
| Construction material | aluminium, steel |
Operating range of the axis
| Axis 1 | ±175°, speed ±180°/s |
| Axis 2 | +85° / -265°, speed ±180°/s |
| Axis 3 | ±160°, speed ±180°/s |
| Axis 4 | +85° / -265°, speed ±180°/s |
| Axis 5 | ±175°, speed ±180°/s |
| Axis 6 | ±175°, speed ±180°/s |
Why choose the CORMAK R950 ROBOT?
The CORMAK R950 robot is a versatile solution for businesses looking to improve repeatability, reduce manual labour and easily automate their workstations. Thanks to its compact design, low weight, high precision and wide range of communication options, the robot can be deployed across many industries.
Accessories, implementation and service
Our range also includes additional accessories for cobots, such as grippers, bases, communication modules and solutions for integration with specific production processes. We also offer training, implementation, technical support and servicing.
We provide Polish-based after-sales service and support at every stage of the robot’s commissioning and operation. We train operators and deploy cobots in production facilities in line with the customer’s requirements.
Opt for automation, precision and operational flexibility – choose the ROBOT CORMAK R950 and boost the efficiency of production processes at your facility.
